8S x 3/8″ BSP EO Male Stud Connector

The main function of Ermeto DIN tube to tube high pressure hydraulic tube fittings is to connect different numbers of tubes. This broad range of Ermeto DIN tube to tube high pressure hydraulic tube fittings, types G, GR, W, T, TR, K, SV, up to WSV is available in steel with Cr(VI)-free surfaces and in a stainless steel version.
Depending on the specific application, the fittings can be delivered with cutting ring (EO-PSR or DPR) or elastomeric seal (EO-2).

Markets:

• Automotive
• Defence
• Energy
• Environment
• Industrial
• Infrastructure
• Machine Tools
• Material Handling
• Mobile
• Oil and Gas
• Power Generation
• Process
• Transportation
• Water

Applications:

• Suitable for general hydraulic applications.

Features/ benefits:

• High corrosion resistance: The Cr(VI)-free surface treatment gives an average corrosion resistance of more than 500 hours to white rust. This attribute helps to extends the life cycle of the fittings.
• Stainless Steel surface: Ermeto DIN tube to tube high pressure hydraulic tube fittings, stainless steel version, have a high corrosion resistance to aggressive media and environmental influences, also a higher temperature resistance, than steel. Thes features extend the range of applications.
• High pressure: Ermeto DIN tube to tube high pressure hydraulic tube fittings can be used in applications of up to 800 bar (S series) and 500 bar (L series), so that the fittings can be used in a wide range of applications.

Part Number – GE08SR3/8CF
Part Number – GE08SR3/8
Brand – Ermeto
Manufacturer – Parker Hannifin
Material – Steel, Cr(VI)-free
Series – Heavy Series
Tube Size – 8S – M161.5
Connection Size – 3/8″ BSP Male
Sealing – Metal sealing edge
Shape – Male stud connector – Male BSPP thread – metal sealing edge (ISO 1179) / EO 24 cone end
Type – Complete with nut and ring
Weight – 0.0807 KG
Customs Tariff Number – 73079910
Country of Manufacture – Germany
