Norgren RA/8160/M/200
ISO Tie Rod Double Acting Cylinder

Norgren are a world leader in motion and fluid control technologies. Wherever precision, speed and engineering reliability are essential, Norgren deliver exceptional solutions which improve the productivity and efficiency of our customers equipment.

Technical Information

Medium Compressed Air Operating Temperature -10 … 80 C Operating Pressure 1 … 16 bar Standard NFE 49-003-1 Port Size G3/4 Cylinder diameter 160 mm Stroke Length 200 mm Operation Double acting Cushioning Adjustable cushioning Magnetic/Non-magnetic Magnetic Theoretical Force 12064 N Materials – Barrel Anodised aluminium Materials – Elastomers Nitrile rubber Materials – Piston Head Seals Polyurethane Materials – Piston Rod Stainless steel (Martensitic) (1.4021) Certification – REACH Available on request Certification – RoHS Compliant Available on request Certification – WEEE NonWEEE Classification – eClass 11 51010101 Classification – HS Code 84123100 Classification – HTS Code 8412310000 Classification – MIL Spec Unavailable Classification – UNSPCS Code 27131701 Classification – US ECCN EAR99 Country of Origin Germany Dimensions – Height 183.5 mm Dimensions – Length 532 mm Dimensions – Width 183.5 mm Weight 19.3 kg Range RA/8000/M Series ISO/VDMA Actuator
