TRACTOR 2SN – Hydraulic Hose 2 Wire Braid – Manuli Hydraulics

Standard, EN 853 2SN, SAE 100 R2AT, MSHA, FRAS

Insert family – Multifit
Cover material – Environment Resistant Synthetic Rubber
Reinforcement material – Steel
Configuration – 4 Braid
Inner Tube Material – Synthetic rubber
Service temp. max C – 100
Service temp. min C – -40
Working peak temp. C – 125
Cover texture – Wrapped
Hose Type – Standard
Unit of Measure – Meter
Colour – Black
Norm – EN 853 2SN, SAE 100R2AT, ISO 1436 2SN/R2AT


Key Features

• EN-DIN and new SAE rated working pressures
• Wide range of type approvals
• Flame retardant property of the cover compound, MSHA approved
• Halogen-Free hose line

An excellent all around hydraulic hose with 2 wire braid structure. Its versitality is upheld with a wide range of approvals from independent world-wide organisarions. The recommended applications include medium to high pressure hydraulic lines.


Main Application
Oil Hydraulics.

Application
Medium-high pressure lines.

Medium Compatibility
Glycols and polyglycol based oils, Mineral oils, Vegetable and rape seed oils, Oils in aqueous emulsion, Synthetic ester based oils, Water.

Cover Resistance
Environment resistant.

Type approvals
ABS, BV, CU-TR, DNV-GL, KRS, LR, MSHA, NK
