Invertek ODE-3-120070-1F12 IP20
Inverter

Invertek Drives Ltd are a leading Welsh electronics manufacturer. They recognises the need to develop as a sustainable industry and note that the prudent and responsible use of natural resources is an important driver of economic growth. Their variable speed drive solutions are utilised across various industries to control the speed and torque of AC induction motors, improving performance and energy efficiency. Invertek have quickly become well known for their innovative design and ease of use, and produce probably the broadest choice of enclosure types from a single manufacturer. With solutions ranging from general-purpose drives to energy-saving and high-performance drives, Inverteks products cater to a wide array of applications.

Single Phase Input/Output, EMC Filter, IP20, General Purpose AC Drive, OPTIDRIVE E3 Series, Simple Setup with 14 Basic Parameters and Functions, For Use with PSC or Shaded Pole Single Phase Motors.

Compact, robust enclosures for panel/cabinet mounting
Sizes 1-5 cover the full power range, up to 37 kW/50 HP
Operates up to 50C
Power supply connects at the top (except frame size 5)
Motor supply connect at the bottom


Technical Information
Input Rating
Supply Voltage: 200-240 V
Input Phases: 1
Supply Current Continuous: 12.9 A
Supply Fuse or MCB (Type B): 16 A
EMC Filter
IP20
General Purpose AC Drive
OPTIDRIVE E3

Output Ratings
Motor Output Rating: 1.5 kW (2 HP)
Output Voltage: 0 Supply Voltage
Output Current : 7 A

Cable Information
Max Supply Cable Size: 8 mm (0.01 sq in)
Max Motor Cable Size: 8 mm (0.01 sq in)
Max Motor Cable Length: 100 m (328 ft)

Please note that the product may not be exact to the image shown.
