Fox K3S3PVCV Pressure Transducer

Designed & produced from 1980, FOX have offered a complete range of hydropneumatic accumulator, pulsation dampeners, pressure switch and vacuum switch, (electromechanical and electronic), transmitter of pressure, level and temperature, temperature switch, level switch and flow switch.
As a confirmation of our commitment to quality research, they have been exporting their products all over the world for more than 40 years.

Technical Information

Working temperature: -25C +85C
Switching frequency: 90 cycles/min
Operating point: adjustable through an internal screw
Switching accuracy: 4% of end of scale at 20C

Fixed Hysteresis Value:
– membrane execution ~ 10% of end of scale at 20C
– piston execution ~ 15% of end of scale at 20C

Weight: 0,08 Kg:
Mechanical Life: 106 cycles at 70 bar (1000 PSI) at 20C

Electric Features:
– Maximum load:0.5A at 250 Volt AC, 0.15 A at 110 Volt DC
– Exchange contacts (Common, NO and NC) SPDT
– Electric connection according to DIN43650 for M2 and M3
– Electric protection according to DIN40050, IP65
– ATEX certification ATEX II 3G Ex nc IIB T6 Gc IP65

Also available:
– Special max pressure
– Special electrical connection
– Special value of hysteresis
– CU-TR for Russian market
– UL-CSA for electric part only
– Electric protection according to DIN 40050, IP54 with P1 protection Cap (Atex execution not applicable)
– Separator in stainless steel, carbon steel or plastic (<10 bar) for corrosive and/or high percentage of solid particles

Please note that the product may not be exact to the image shown.
