Rexroth R901099808
Micro Pressure Switch

As a leading specialist in drive and control technology, Bosch Rexroth has a unique level of technological expertise. The Bosch Group isa leading global supplier of technology and services.

200 bar, micro switch with NC contact/NO contact function, device connector DIN EN 175301-803 (large cubic connector)

Potential-free switching of currents from 1 mA to 2.0 A. Small hysteresis, depending on the set switching point. High repetition accuracy < 1% of the set pressure.

• Internal hexagon
• Piston type pressure switch
• Micro switch with NC contact/NO contact function
• Flange connection
• Without mating connector, connector DIN EN 175301-803
• With NBR seals

Technical Specifications

Product family: HED 8

Operating pressure, max. [bar]: 200

Type of connection: Flange connection

Output signal: Micro switch with normally closed contact/NO contact function

Supply voltage: 12…250 V AC/DC

Electrical connector: Connector, 4-pole (3 + PE)

Electrical connection description: Connector 4-pole (3 + PE) according to EN 175301-803

Conformity description: CE according to Low-Voltage Directive 2014/35/EU

Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD

Seals: NBR
