Aventics 821303404 Emerson Filter Series NL2-FLS

Aventics is a manufacturer of pneumatic components and systems with facilities in Europe, USA and China. Aventics pneumatics facility manufactures pneumatic valves, pneumatic cylinders, directional control valves, pressure control valves, electro-pneumatic valves, solenoid valves, pneumatic fittings, flow controls, actuators, marine propulsion controls and more.

Aventics 821303404 Filter, Series NL2-FLS (NL2-FLS-G014-PBS-AO-05,00)

The pressure dew point must be at least 15 C under ambient and medium temperature and may not exceed 3 C .

Suitable for use in Ex zones 1, 2, 21, 22

Note: Polycarbonate reservoirs are susceptible to solvents.

A change in the flow direction (from air supply on the left to air supply on the right) occurs by rotating installation by 180 about the vertical axis. Also suitable for separation of fluid oil or water due to the design.

Technical Information
Pneumatic port: G 1/4
Condensate Drain: fully automatic, open without pressure
Flow Qn: 2100l/min
Ambient Temperature Max: 60DegC
Ambient Temperature Min: -10DegC
Working Pressure Max: 16 Bar
Working Pressure Min: 2 Bar
Weight: 0.392 kg

Please note that the product may not be exact to the image shown.
